  F

  In SU 2024, in a newly created and empty file, the first line (even formed from multiple edges) is not visible, only the second is visible, or if the file is not empty.
  I tested in SU 2023 and 2022, and this bug is only in 2024.

• Post Processing

  No decsciption available
  78
  Topics
  449
  Posts

  D

  @walter007 looking at the References list, there's a blank reference which, when clicked on, selects a SketchUp viewport that is supposed to come from a model called CASAS 3d final.skp. Unfortunately that reference file does not exist within the SketchUp file as it ought to. When I've seen this sort of thing before the cause is incorrectly inserting the SketchUp file (copying from SketchUp and pasting in LayOut) or when the SketchUp model file is saved somewhere like iCloud.
  Screenshot - 9_3_2024 , 7_29_59 PM.png

  You could try the following and see if it works to fix this. First make sure that both the SketchUp file AND the LayOut file are saved on the internal drive of your computer. Then, in Document Setup>References, highlight the empty line. Click on Relink and then choose the SketchUp file.

  Note the dark background in the Camera section of the SketchUp Model panel in the tray. This shows the camera properties have been overridden from those of the scene. After you relink the model file, reset the Camera. If you need to change the viewport, first go into SketchUp and make sure the scene is set up correctly. Best practice is to avoid overriding the Camera properties from the scene.
