I do a lot of this kind of thing. I use TIG's Tangent Tools to aid in working out the tangents and instead of using circles for the bends in the belt I use the Arc tool between the tangent points.

Although this one is a round belt the idea is the same to create the Follow Me path.
Screenshot - 1_20_2025 , 1_29_40 PM.png

A quick example.
Screenshot - 1_20_2025 , 1_43_23 PM.png

-Circles represent the surface of the pulleys. Guide lines and points after using Common Tangents in Tangent Tools.
-Circles replaced with arcs between the guidepoints at the tangents.
-Edges drawing in to complete the loop.
-Offset to define the thickness of the belt.
-Belt extruded to final width.
