[Plugin] ClothWorks v1.8.0 - 28 Apr 2024

inuk228

스케치업 2026 (버전 26.2.243.64비트) 사용자 입니다. 그래픽카드 nvidia geforce rtx 2070 super 인데

TIG

@inuk228
And your question is ?

Mike Amos

Korean language detected by google.

I am a SketchUp 2026 (version 26.2.243.64-bit) user. My graphics card is an NVIDIA GeForce RTX 2070 Super.

포럼 사용자들에게 질문이 있으신가요?
poleom sayongjadeul-ege jilmun-i iss-eusingayo?

What is your question for the forum?

PEDROELIASCARLOS1998

Hello,

I'm having an issue with the plugin. It seems that the installation file may be corrupted or possibly infected, as my antivirus detects it as a threat during the download.

Also, when I manage to download and install the plugin in SketchUp, SketchUp starts freezing and crashing immediately after the installation.

Could you please check whether there is an issue with the installation file or provide an updated version?

Thank you!

Dave R

I haven't had any freezing or other weird behavior with Clothworks. It works as expected for me.

Which version do you have installed? What operating system? What SketchUp version? What version of the Sketchucation ExtensionStore do you have installed?

voegel

Excellent work, but how can I use it for (maybe rare) reversed gravity use cases?

Robert Hooke (1635-1703)
Robert Hooke (1635-1703).jpg

Dave R

@voegel said:

but how can I use it for (maybe rare) reversed gravity use cases?

Invert the object after running the extension.

voegel

I know that workaround but that is not what I really like

Sagrada Familia Museum - Barcelona - Hanging Model (= analog computing)

jsinmichael

Can you please confirm that this extension works with the latest SU version? Thanks!

Rich O Brien

@jsinmichael said:

Can you please confirm that this extension works with the latest SU version? Thanks!

It does. You can install it using Sketchucation Tools: https://sketchucation.com/plugin/696-sketchucationtools and trial it to check for yourself

Dave R

Visual proof:

Carlarochasoares

Hi everyone,

I'm trying to model a tensile tent in ClothWorks, with one side attached to the roof of a house.

I'm looking for some advice on the best ClothWorks settings for this type of tensioned membrane, but my main difficulty is positioning the pins accurately.

Is there a way to move the pins more precisely? The arrows are very large, so I have to zoom out to click on them, which makes it difficult to position the fixing points accurately.

Any advice would be really appreciated. Thanks!

FlawinneF

Do you know if the developer is going to release an update for SketchUp 2027?

TIG

@anton_s
He is the developer and only he can confirm compatibility - and I know the PluginStore only lists up to v2024 for 'compatibility',
BUT if it's working in newer versions than that [and it seems that others have been using it successfully in v2026] then it should also work in v2027.
Download it and try it - report back on your experiences with it in v2027 - it will be helpful feedback for others and the author...

Dave R

@TIG This is the error when opening SU2027.

Extension Errors Report
SketchUp: 27.0.264
OS: Windows 11
Ruby: 3.4.9

Extension: ClothWorks (1.8.0a)
Error: IOError (Stage directory, "c:/users/drkr4/appdata/roaming/sketchup/sketchup 2027/sketchup/plugins/ams_clothworks/libraries/stage/win64/3.4", is missing!)
c:/users/drkr4/appdata/roaming/sketchup/sketchup 2027/sketchup/plugins/ams_clothworks/extension_manager.rbe:97:in 'AMS::ClothWorks::ExtensionManager#require_all'
c:/users/drkr4/appdata/roaming/sketchup/sketchup 2027/sketchup/plugins/ams_clothworks/main.rbe:747:in '<main>'
C:/Program Files/SketchUp/SketchUp 2027/SketchUp/Tools/extensions.rb:209:in 'Kernel.eval'
C:/Program Files/SketchUp/SketchUp 2027/SketchUp/Tools/extensions.rb:209:in 'Sketchup.require'
C:/Program Files/SketchUp/SketchUp 2027/SketchUp/Tools/extensions.rb:209:in 'SketchupExtension#load'
C:/Users/drkr4/AppData/Roaming/SketchUp/SketchUp 2027/SketchUp/Plugins/ams_ClothWorks.rb:38:in 'Sketchup.register_extension'
C:/Users/drkr4/AppData/Roaming/SketchUp/SketchUp 2027/SketchUp/Plugins/ams_ClothWorks.rb:38:in '<module:ClothWorks>'
C:/Users/drkr4/AppData/Roaming/SketchUp/SketchUp 2027/SketchUp/Plugins/ams_ClothWorks.rb:7:in '<module:AMS>'
C:/Users/drkr4/AppData/Roaming/SketchUp/SketchUp 2027/SketchUp/Plugins/ams_ClothWorks.rb:6:in '<top (required)>'

rv1974

@TIG many v2026 compatible plugins don't work in v2027. all mindsight, TT, this one, etc

Dave R

@rv1974 said:

@TIG many v2026 compatible plugins don't work in v2027. all mindsight, TT, this one, etc

Which "TT" extensions don't work in 2027? All the ones I have work as expected.

TIG

So it looks like @anton_s needs to comment / update [and others] ...
It looks like Anton needs some ../ams_ClothWorks/libraries/stage/win64/3.4 .so file making and adding for compatibility - the Ruby version was updated to 3.4 in v2027 !

drjennings7

Hi this is a question for @anton_s

I love ClothWorks, and use it all the time professionally. I also teach and get my students to start using your free version, and most buy the full license. It is a great tool. However I was distressed to find that it does not run on SU 2027. It is early in the year I understand, but do you have plans to upgrade the plugin to work with the new Ruby environment on SU 2027?

I sincerely hope that you do, I would be happy to purchase a new pro licence from you if needed and i am sure a lot of the users in our community would as well.

My thanks,
DRJENNINGS7

pipinek

Greetings,

any chance to get an update for SU 2027?
