How can I make a twisted window?
-
Hi guys! What
s up? Im new at the sketchup and at my work i need to make a twisted window, Does someone know how i can draw this? Or maybe Does it have a plugin that facilitates the modeling?I uploaded a photo to explain my problem
-
Hi Marco and welcome to SCF!
The file itself would be better. I cannot really see what's going on in that far end of the image...
-
option 1
build the window square... and true... then use Fredo's scaling tools to twist it.option 2
use curviloft to build one window and copy along the path. -
Kris, he says he is completely new to SU. We cannot bombard him with complex plugins on the first day - and also he should first learn how to do it with native tools!
-
ahh sorry... native tools... mmm that will be hard.
-
Hi Marco,
For presentation purposes attached file may explain how to do this with native SU.
To narrow down inaccuracy to ~0mm you may need to repeat the few steps on top geometry before smoothing edges.
Toggle 'Hidden Geometry' on/off in last scene to see which smooth edges I mean.So in short: make correct top selection > rotare and scale (rotate and scale) > final correcton at pole > smooth.
-
@krisidious said:
ahh sorry... native tools... mmm that will be hard.
No prob, Kris (and he was not asking for native tools only) it's just the learning curve, you know.
Wodan; I really wonder how you could get any relevant info from that skewed image!
-
You can do it several other ways too
-
first of all, i want to thank u guys^^
So, maybe i'm not so new in the sketchup...
Oh sorry i'm without the file, in monday i post here again. But let me make a question, how can i decrease the file size, cause it has 20mb =[
Thxx for the replies!!
-
Here is the file
I reduced the size file =], i don`t know why but reduced a lot
So thks!!
Maybe i will need a lot of help in this model, and hopefuly i found this forum.
-
Hey guys
I don`t know how but i could reduce the file size. =], Maybe is because the components definitions someone know how to explain how i can reduce the number of components definitions
and this is the file:
-
Thank u so much for the possibilites, i`m gonna try now
-
Yeah, it
s ok now, thank u guys! I used the Frodo Scale something like that, and it was ok. Thk u TIG, cause i saw ur explanation about the Edge Extrude and ive done the domeI need to reduce the size of my file, i could reduce the file attached but i don
t know what ive done. XDThe original file have 17mb, i will try to fix it
This forum is really nice, i`m so glad i found it
Hugs!!
